Developed by Ligier Advanced Technologies (formerly Mygale), the Formula Ford FF200 features a tubular chassis and is powered by the FF1600 EcoBoost engine. Built to meet the highest safety standards (FIA Article 277 crash test homologation), this single-seater dominated the 2014 British Formula Ford Championship, making up 99% of the grid. Fast, reliable, easy to maintain, and cost-effective, it quickly became a benchmark for young drivers looking to develop their skills at the wheel of a competitive race car.

Technical sheet

CHASSIS

  • Tubular steel spaceframe chassis
  • Weight: 465 kg

MOTEUR

  • 1.6 Ford EcoBoost 200,
  • direct injection, turbocharged,
  • all aluminium

SUSPENSIONS

  • Front : twin shocks or mono shock pushrod activated
  • Rear : twin shocks pushrod activated
  • Aerodynamic section wishbones and pushrods with staked bearings
  • Fabricated in high quality aircraft specification tubing.
  • Aluminium hub

Gearbox

  • Hewland FTR,
  • 6-speed sequential transmission + reverse gear.

Brakes

  • Lightweight double acting AP Racing calipers
  • Dual circuit system using  aero spec hoses
  • Adjustable from cockpit
  • Left foot braking

Tyres

  • Dunlop slicks and wets
    • Front: 7.5“ - 21x13“
    • Rear: 8.5“ - 22x13“

Wheels

  • Aluminium Rimstock centre-lock
    • Front: 7.5x13“
    • Rear: 8.5x13“

Steering

  • Equipée d'un système de démontage rapide du volant

SECURITE

  • Front and rear carbon crash structures
  • Full-height cockpit side-impact protection panels
  • Extractable seat
  • FIA- specification headrest
  • Wheel tethers
  • FIA homologated collapsible steering column
  • 2, 5 kg fully plumbed-in extinguisher system

Bearings

  • Aircraft quality joints

TRANSMISSION

  • Assembly SADEV + hub in aluminium

Dampers

  • Koni or Quantum optional

Cooling

  • Race radiator + air duct
  • Intercooler + air duct

Electronics

  • Ford specification harness, dash and steering wheel

Aerodynamics package

  • Carbon front wing with adjustable flaps
  • Lower and upper aluminium rear wing adjustable
